Pyroelectric infrared motion sensors from Panasonic for optimal usability and reliability
Compact, high-sensitivity, circuit-integrated package realized by unique design concept
Wide range of lens lineup, and low current consumption types are available

Compact, high-performance pyroelectric infrared sensor

Types and advantages of PIR Motion Sensors

Special designs from Panasonic that provide high sensitivity and reliability

[Short] PIR "PaPIRs" All-in-one

PIR Motion Sensors PaPIRs Quick Digest

[Short] PIR sensor "PaPIRs" ideas

PaPIRs -How to Choose Lens type-

PaPIRs -How to Choose Sensor Type-

Interview on The Achievement of Producing 100 Million Units. What is behind the popularity of PaPIRs Passive Infrared Motion Sensors.  Click here for details

Article on the achievement of producing 100 Million Units

Small Size, Big Energy Savings. Click here for details

Small Size, Big Energy Savings

Features

Two times better sensitivity

The sensitivity has been significantly improved thanks to a unique slit design of the pyroelectric elements. The separated sensing areas prevent thermal crosstalk between the single sensing elements. Therefore, reliable detection is possible even if the temperature difference between the background (e.g. floor / wall) and the target object (human) is small. (e.g. ΔT = 4℃)
Slit design

Easy design-in

The integrated amplifier / comparator circuit inside a TO-5 metal can (digital type) prevents interferences caused by electromagnetic fields, such as those generated by cell phones and wireless devices. A special differential circuit design is introduced for the EKMB 6μA type for applications where a high noise resistance is required (up to GHz range). Easy design-in

Small and fancy lens design

Thanks to the special design of the small pyroelectric elements, it is possible to use a smaller lens size while keeping the same detection area and distance compared to conventional sensors. Small and fancy lens design

Four times better signal-to-noise ratio

Improved signal-to-noise ratio thanks to a special I/V circuit which is used for converting a current signal from the pyroelectric element to voltage. Panasonic PIR motion sensors perform by the feedback capacitor and the operational amplifier, different from the conventional FET-type, thereby decreasing the probability of false alarms due to temperature fluctuation.
Conventional: PIR
Conventional: S/N ratio

Lead-free pyroelectric element

A ferroelectric Lithiumtantalate (LiTaO3) single lead-free crystal is used as the pyroelectric element for Panasonic PIR motion sensors. Conventional PIR motion sensors normally use a ceramic base material (e.g. PZT) for the pyroelectric element, which contains lead in many cases.

Low current consumption EKMB (WL)

Reduction of current consumption (1, 2 or 6μA) thanks to the special circuit design technology allows battery life to be extended for battery-driven products.
Environmental image

Application examples

It has various usages,including IoT-related devices and systems such as occupancy detection, monitoring, home appliance control, and intrusion detection, as well as high-bay lighting and street light control.

Application examples

Industry examples

Home appliances: wide range of lens lineup, and slight motion performance

Home appliances

IoT: radiation noise resistance and low current consumption. (adjacent to wireless module, battery driven)

IoT

Lighting: S/N ratio and Slight motion performance. (Reduction of malfunctions and non-operations)

Lighting
